- Supports 1000 users, 3000 fingerprints and 300 000 records.
 - Supports card, remote, PIN, fingerprint and combination of these.
 - Connection to PC via TCP/IP or RS-485.
 - Connection to reader via Wiegand or RS-485.
 - Flexible response to project needs: 2 doors 1 address or 1 door 2 addresses.
 - Built-in web server, with primary and secondary control modes.
 - Primary control: manage up to 19 sub-controllers.
 - Secondary control: can be added to multiple platforms.
 - Surface or DIN Rail installation.
 - 12Vdc and PoE power supply.
 - Degree of protection: IK06.
 - Dimensions and weight: 186.4x185.8x58.3mm / 0.99kg.

** ONLY compatible with ASR2200A-B.
