- PoE In: powered by PoE. Gigabit PoE input and 100Mbps PoE output, a single cable meets the demand for power and signal transmission.
- Red 90W port => PoE up to 250m to power cameras with a maximum power consumption of 90W. Supports IEEE802.3af, IEEE802.3at, IEEE802.3bt and Hi-PoE standards.
- Port 1-4: 4xRJ45 10/100 Base-T (PoE)
- Port 5: 1xRJ45 10/100/1000 Base-T (PoE In)
- 4 PoE ports, port 1<90W, ports 2-4<30W, total 90W.
- Compliant with IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE 802.3z.
- PoE Watchdog.
- Working temperature: -30°C ~ +65°C.
- Dimensions and weight: 150x100x30mm / 0.47kg.
